Loadcell SENSORTRONICS 65114
• Rated capacities of 50,000 to 100,000 pounds;25 to 50 metric tonnes
• Stainless steel, welded seal construction
• 30 feet standard cable length
• Trade certified for NTEP Class IIIL: 10000 divisions andOIML R60 3000 divisions
• Welded Sensorgage™ sealed to IP67 standards
• Factory Mutual System Approved for Classes I, II, III;
• Divisions 1 and 2; Groups A through G. Also, non-incendive ratings (No barriers!)
Optional
Fully hermetically sealed available to IP66/68 standards
| Model | 65114 | |
| Rated Capacity (lbs) | 50k, 100k lbs | |
| Rated Capacity (tf) | 25, 35, 50 tf | |
| Accuracy Class According to OIML-R-60 | OIML R60 | |
| Max. Number of Verification Intervals | 3000 | |
| Y= Emax/Vmin | 8333 | |
| Rate Output mV/V (lbs) | 2.0 | |
| Tolerance on Rate Output mV/V (lbs) | ± 0.25 | |
| Zero balance | ± 1.0 | |
| Combiner Error %RO | ± 0.02 | |
| Non -Repeatability %RO | ± 0.01 | |
| Zero Creep for 30min %RO | ± 0.017 | |
| Temp. Effect on Min. Dead Load Output %S/5 0C | ± 0.0010 | |
| Temp. Effect on Sensitivity %S/5 0C | ± 0.0007 | |
| Safe sideload % Emax | 100 | |
| Maximum Safe Over Load % Emax | 150 | |
| Ultimate Over Load % Emax | 300 | |
| Excitation Voltage | Recommended (V) | 5 ~ 20 |
| Maximum (V) | 25 | |
| Resistance | Input (Ω) | 1000 |
| Output (Ω) | 990~ 1010 | |
| Insulation (MΩ) | > 1.000 | |
| Compensated Temperature Range 0C | -10 ~ +40 | |
| Operating Temperature Range 0C | -18 ~ +65 | |
| Material | Stainlees steel | |
| Cable Specification | ø 8.0 x 4P x 9m | |
| IP | 67 | |
