Loadcell HBM RSCC
– Load cell with SG measurement system
– Maximum capacities: 50 kg to 5 t
– Hermetically sealed (IP68)– Rust‐resistant materials
– Legal‐for‐trade to 3000 divisions, testreport per OIML‐R60 for class III scales
– Meets EMC requirements as perEN 45 501
– Six‐wire circuit
– Ex‐protection version (optional)
| Model | RSCC | |
| Rated Capacity (kgf) | 50, 100, 200, 500 kgf, 1, 2, 5 tf | |
| Accuracy Class According to OIML-R-60 | OIML | |
| Max. Number of Verification Intervals | C3 – 3000 | |
| Y= Emax/Vmin | 10000 | |
| Rate Output mV/V | 2 | |
| Tolerance on Rate Output mV/V | ± 0.25 | |
| Temperature coefficient of sensivity %RO | ± 0.0140 | |
| Zero signal mV/V | 0 ± 0.1 | |
| Relative reversibility Error %RO | ± 0.0166 | |
| Non – linearity %RO | ± 0.0166 | |
| Zero Creep for 30min %RO | ± 0.0166 | |
| Limit Load % Emax | 150 | |
| Limit lateral Loading% Emax | 100 | |
| Breaking Load % Emax | 300 ( 500kgf, 1, 2 tf) – 200 ( 50, 100, 200kgf, 5tf) | |
| Excitation Voltage | Recommended (V) | 5 |
| Maximum (V) | 12 | |
| Resistance | Input (Ω) | 389 ± 15 |
| Output (Ω) | 350 ± 1.5 | |
| Insulation (MΩ) | > 1.000 | |
| Compensated Temperature Range 0C | -10 ~ +40 | |
| Operating Temperature Range 0C | -30 ~ +70 | |
| Material | Stainless steel | |
| Cable Specification | ø 5 x 6P x 7.6m | |
| IP | 68 | |
