Loadcell HBM HLCB1C4
Maximum capacities: 110 kg … 10 t
Hermetically encapsulated (IP68)
Rust‐resistant materials
Low height of construction
Legal for trade per OIML R60 to 6000 divisions
Legal for trade per NTEP (USA) III M5000
Explosion protection versions as per ATEX andIECEx, FM (US/CA)
| Model | HLCB1C4 | |
| Rated Capacity (kgf) | 220, 550 kgf, 1.1 tf | |
| Accuracy Class According to OIML-R-60 | OIML | |
| Max. Number of Verification Intervals | C4 – 4000 | |
| Y= Emax/Vmin | 10000 | |
| Rate Output mV/V | 1.94 | |
| Tolerance on Rate Output mV/V | ± 0.1 | |
| Temperature coefficient of sensivity %RO | ± 0.0105 | |
| Relative reversibility Error %RO | ± 0.0125 | |
| Non – linearity %RO | ± 0.0166 | |
| Zero Creep for 30min %RO | ± 0.0166 | |
| Minium dead load output return %RO | ± 0.0125 | |
| Limit Load % Emax | 150 | |
| Limit lateral Loading% Emax | 100 | |
| Breaking Load % Emax | 300 | |
| Excitation Voltage | Recommended (V) | 5 ~ 10 |
| Maximum (V) | 10 | |
| Resistance | Input (Ω) | 350 ~ 480 |
| Output (Ω) | 350 ± 0.12 | |
| Insulation (MΩ) | > 1.000 | |
| Compensated Temperature Range 0C | -10 ~ +40 | |
| Operating Temperature Range 0C | -18 ~ +65 | |
| Material | Stainless steel | |
| Cable Specification | ø 5.4 x 6P x 6m | |
| IP | 68 | |
