Product Characteristics
Low profile
Intergrated loading base
Low deck high capacity scale application
Nickel plated steel construction
| Model | CPA | |
| Rated Capacity (tf) | 500kgf, 1, 2, 3, 5tf | |
| Accuracy Class | D3 | |
| Combined Error (% R.O) | ≤ 0.14 | |
| Creep for 30 min (% R.O) | ≤ 0.03 | |
| Excitation | Recommended (V) | 10 |
| Maximum (V) | 15 | |
| Compensated Temperature Range (0C) | -10 ~ +40 | |
| Operating Temperature Range (0C) | -40 ~ +80 | |
| Material & plate | Nickel plated steel | |
